Description
Features
- Piezoresistive sensor technology
- Ranges
- 0-50 inH2O to 0-400 inH2O
- 0-5 psi to 0-400 psi
- Accuracy up to 0.125% BFSL
- Temperature compensated from 32 to 122˚F
- Multiple voltage or current output options
- G 1/2B process connection with removable protective cap
- Vented polyurethane or FEP cable
- Stainless steel body with Hastelloy C4 available for aggressive media
- 2004/108/EEC, EN 61 326 Emission (Group 1, Class B) and Immunity (industrial locations)
- Rated IP 68 for permanent submersion
- Cable supports over 220 pounds of strain
- Optional lightning protection
- Optional temperature measurement
