Description
Features
- DC Voltage Range: 0 to 1020V; Accuracy: 80ppm
- DC Current Range: 0 to 10A; Accuracy: 0.03%
- AC Voltage Range: 0 to 1020V (10Hz to 2kHz); Accuracy: 0.08%
- AC Current Range: 0 to 10A (10Hz to 2kHz); Accuracy: 0.1%
- Resistance (simulated) Range: 0 to 10MΩ; Accuracy: 0.02%
- Resistance (passive) Range: 10Ω to 100MΩ (decades); Accuracy: 0.02%
- Capacitance (passive) Range: 10nF to 1µF; Accuracy: 0.8%
- Insulation Resistance Range: 1MΩ to 1GΩ; Accuracy: 0.8%
- PRT Resistance Range: -200 to 800°C; Accuracy: 20ppm
- Thermocouple Simulation Range: J,K,T,R,S,B,N,E,L,U,C; Accuracy: 0.22°C
- Rugged, ultra-portable design
- Fast warm up time
- Full output protection using built-in I-GUARD system
- Transit case, benchtop versions available
- Benchtop can be rack mounted with accessory
- USB interface
- Dedicated thermocouple output socket
- Graphic LCD display with backlight for clear, bright presentation of functions & settings
- Numeric keypad for easy entering of test values
- Includes ISO17025 factory certificate
