Description
Features
- PT100 sensor, α = 0.00385
- -58 to 842°F (-50 to 450°C) thin film element
- -321 to 572°F (-196 to 300°C) wire wound element
- Minimum insulation resistance measured at 500VDC
- 1000MΩ at room temperature
- 400MΩ at max temperature
- 10.8 seconds max time response required to reach 50%
- ±0.15°C (0.059Ω) max ice-point resistance shift
- Following 1,000 hours at max temp
- Self heating of an average of 0.32 °C/mW
- Spring-loaded sensor mounting styles available
- Hazardous location product approvals optional
