Description
Accuracy:-
- Better than 0.05% of selected rang
Response time (analog):-
- 1-60 seconds
Temperature coefficient:-
- 50 ppm / °C (0.005% / °C)
Input types:-
- RTD: Pt50, Pt100, Pt200, Pt500, Pt1000, Ni50, Ni100,
- Ni120, Ni1000
- Thermocouple: B, E, J, K, L, Lr, N, R, S, T, U, W3, W5
- Bipolar mV signals
- Resistance signals
Output types:-
- 4-20 mA
Voltage drop:-
- 10 VDC (backlight off)
- 12 VDC (backlight on)
Operating temperature:-
- -40°C to +85°C
Humidity:-
- 0-100% relative humidity
EMC:-
- EMC immunity influence < ±0.1% of selected range
- Extended EMC: NAMUR NE21 burst, A criterion – as well as NE43 and NE89
- EN 61326-1 certification
Configuration types:-
- LOI, PC with HART or HART terminal
Display type / diameter:-
- Dot matrix / 60 mm
Number of process value digits:-
- 5
Buttons:-
- Three optical buttons: up arrow, down arrow and OK
Backlight color:-
- Selectable red or white
