Description
Specification
Technical Data
Nominal size
- MEX2 : 50 mm
- MEX3/MEM3 : 63 mm
Measurement range:-
- MEX2/MEX3 : -1 … 0 to 0 … 1000 bar
- MEM3 : -1 … 0.6 to 0 … 400 bar
Pressure limitation:-
- Steady : 75% of full scale value
- Fluctuating : 65% of full scale value
- Short time : 100% of full scale value
Accuracy:-
- Class 1.6 (according EN837-1)
Protection rating:-
- IP 65 (EN 60529)
Process Connection:-
- MEX : Stainless steel 1.4404 (AISI 316L)
- MEM : Monel 400
Bourdon tube:-
- MEX : Stainless steel 1.4404 (AISI 316L)
- MEM : Monel 400
Case:-
- Stainless steel 1.4301 (AISI 304)
- Option : stainless steel 1.4404 (AISI 316L)
Bezel ring:-
- Stainless steel 1.4301 (AISI 304)
- Option : stainless steel 1.4404 (AISI 316L)
Movement:-
- Stainless steel
Window:-
- Instrument glass
Window gasket:-
- Elastomer
Dial:-
- Aluminium, white
Pointer:-
- Plastic, black
Temperature:-
- Ambient : -20 … +70°C
- Medium : -40 … +200°C (not filled)
- For liquid filled version see ordering details.
- The case temperature must not exceed +70°C
- Storage : -40 … +70°C
Thermal drift:-
- ± 0.4% F.S. / 10 K (reference : 20°C)
Safety:-
- S1 according EN837-1
- (with window polycarbonate or laminated safety glass)
Description
Main Features:
- For corrosive gasses and liquids
- Class 1.6 according to EN 837-1
- Wetted parts: Stainless steel (MEX) or Monel (MEM)
- Lloyd`s Register approval
- Option : liquid-filled for ap- plications with pulsations or vibrations
- Option : case material 1.4404 (316L) for aggressive atmos- phere
Applications:
- Food and Beverage
- Laboratory & Medical
- Oil & Gas / Chemical
- Water & Waste water
- Energy
- Transportation and Logistics
- Machinery
