Description
Features
- Excellent liquid and gas compatibility
- Compact, submersible design
- Ranges to 30 PSIG
- Accurate to ±0.5% BFSL
- Outputs: 0.5 to 4.5 V ratiometric, 1 to 5 V, or 4 to 20 mA
- Over Range Protection: 2X Rated Pressure
- Burst Pressure: 5X or 1,250 PSI (whichever is less)
- Pressure Cycles: Greater than 50 Million
- Cost effective alternative to ultrasonic & radar sensor technologies
- Class I Div 1, Groups C &D, intrinsically safe; w/ approved barrier
- Works with reflective liquids
- Will not fail due to vapor
- 1/4″ NPTF process connection
